ASI1201E

Features:

Support 30,000 valid cards & 60,000 records
Support multiple cards (default IC card) (“-D” means ID EM card)
Support card, password and combination
TCP/IP to PC
Wiegand or RS-485 interface to reader
Door time out alarm, intrusion alarm, duress alarm and tamper alarm
Anti-passback, multi-card open
Water-proof design
Support 128 efficient time and holiday schedules
Watch dog function ensure device free from halting
IP66 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)

System
Main Processor	32 Bit
Input/Output Ports
Input	Door sensor x 1, Exit button x 1
Output	Relay x 1 (Door lock,)
Reader	Reader x 1
Card Read
Read Format	13.56MHz
Read Range	1cm–2cm (max.)
Response Time	<0.1s
Capacity
Cardholders	30,000
Events	60,000
Function
User Management	General, VIP, Guest, Patrol, Black list, Duress
Alarm Function	Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm
Period Setting	Support 128 groups of schedule, 128 groups of periods and 128 groups of holiday periods
Interface
To PC	RJ45(10/100M)
To Reader	Wiegand26/34, RS485
Genreal
Ingress Protection	IP66 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
RTC	Yes
Beep Tone	Buzzer
Keyboard	Sensitive touch keypad with blue backlight
Power Supply	DC 9-15V/100mA
Operating Temperature	-10°C to +55°C
Working Humidity	10%RH–90%RH (no-condensation)
Dimension(W×D×H)	62.0mm×142.0mm×23.0mm
Weight	0.5kg
Working Environment	Outdoor
Certificates
CE	Yes
FCC	Yes
