Dahua AI PTZ IP Cameras-SD5A225XA-HNR
2MP 25x Starlight IR WizSense Network PTZ Camera
Camera |
|
| Image Sensor | 1/2.8″ CMOS |
| Effective Pixels | 1920 (H) × 1080 (V), 2 Megapixels |
| Scanning System | Progressive |
| ROM | 4GB |
| RAM | 1GB |
| Electronic Shutter Speed | 1/3–1/30000 s |
| Minimum Illumination | Color: 0.005Lux@F1.6
B/W: 0.0005Lux@F1.6 0Lux (IR light on) |
| S/N Ratio | N/A |
| Illumination Distance | 150 m (492.13 ft) |
| Illumination On/Off Control | Zoom Prio/Manual/SmartIR/Off |
| Illumination Number | 4 |
Lens |
|
| Focal Length | 5.4 mm–135 mm |
| Max Aperture | F1.6-F3.5 |
| Angle of View | H: 58.7°–3.1°; V: 33.2°–1.7°; D: 67.3°–3.9° |
| Optical Zoom | 25x |
| Focus Control | Auto/Semi-Auto/Manual |
| Close Focus Distance | 0.1 m–1.5 m (0.32 ft–4.92 ft) |
| Iris Control | Auto/Manual |
DORI Distance |
|
| Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. | |
| Distance | |
| Detect | 1655 m (5429.79 ft) |
| Observe | 657 m (2155.51 ft) |
| Recognize | 331 m (1085.96 ft) |
| Identify | 166 m (544.62 ft) |
Pan / Tilt / Rotation |
|
| Pan/Tilt/Rotation | Pan: 0°–360°; Tilt: -15°–+90° |
| Manual Control Speed | Pan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s |
| Preset Speed | Pan: 400°/s; Tilt: 300°/s |
| Presets | 300 |
| Pattern | 5 |
| Scan | 5 |
| Tour | 8 (up to 32 presets per tour) |
| Speed Adjustment | Support |
| Power-off Memory | Support |
| Idle Motion | Preset/Tour/Pattern/Scanning |
| Protocol | DH-SD Pelco-P/D (auto recognition) |
General Intelligence |
|
| Event Trigger | Motion detection, Video tampering, Network disconnection, IP address conflict, Illegal access, Storage anomaly |
| IVS | Tripwire, Intrusion,Abandoned/Missing |
Artificial Intelligence
|
|
| People Counting | N/A |
| Perimeter Protection | Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| SMD Plus | Support |
| Auto Tracking | Support |
| Face Detection | Support |
| Smart Capture | Support human, motor vehicle and non-motor vehicle image capture. |
Video |
|
| Compression | H.265/H.265+/H.264+/H.264/MJPEG (Sub Stream) |
| Streaming Capability | 3 Streams |
| Frame Rate | Main stream: 1080P/1.3 M/720P (1–50/60 fps)
Sub stream 1: D1/CIF (1–25/30 fps) Sub stream 2: 1080P/1.3M/720P/D1/CIF (1–25/30 fps) |
| Resolution | 1080P (1920 × 1080); 1.3 M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | Variable/Constant |
| Bit Rate | H.265/H.264: 3 kbps–20480 kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC | Support |
| HLC | Support |
| WDR | 120dB |
| Gain Control | Auto / manual |
| Noise Reduction | 2D/3D |
| White Balance | Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp |
| Motion Detection | Support |
| Region of Interest | Support |
| Electronic Image Stabilization (EIS) | Electronic |
| Defog | Support |
| Digital Zoom | 16x |
| Flip | 180° |
| Privacy Masking | Up to 24 areas, and up to 8 areas in the same view |
Network |
|
| Ethernet | 1 RJ-45 Port 10/100Base-T |
| Protocol | IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Interoperability | ONVIF Profile S&G&T; CGI |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 20 (Total bandwidth 64M) |
| Edge Storage | FTP; Micro SD card (256G); NAS |
| Web Viewer | IE7 and newer versions Chrome 42 and older versions Firefox 52 and older versions Safari |
| Management Software | Smart Player / Smart PSS / DSS / Easy4ip |
| Smart Phone | IOS, Android |
Certifications |
|
| Certifications | CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB,ANSI C63.4- 2014UL:UL60950-1+CAN/CSA C22.2,No.60950-1 |
| Audio | |
| Compression | G.711A;G.711Mu;G.726;AAC;MPEG2-Layer2;G.722.1;G.729;G.723 |
Port |
|
| Video Interface | N/A |
| RS485 | N/A |
| Audio I/O | 1 (LINE IN; bare wire) |
| Alarm I/O | 1 (LINE OUT; bare wire) |
| Alarm I/O | 2/1 |
| Power | |
| Power Supply | AC24V/3A±25% POE+ |
| Power Consumption | 8W
20W (IR light on) |
Environmental |
|
| Operating Conditions | –40°C to +70°C (–40°F to +158°F) |
| Operating Humidity | ≤95%RH |
| Protection | IP67; IK10; TVS 6000V lightning protection; surge protection |
Structure |
|
| Casing | Metal |
| Dimensions | Φ190 mm×332 mm (7.48″×13.07“) |
| Net Weight | 4.7 kg (10.36 lb) |
| Gross Weight | 8 kg (17.64 lb) |
