DSS4004-S2

Features:

Cost-effective
Preloaded with linux-optimized easy-to-use DSS Express, which makes the deployment simplified
Pre-activated 512 video channels can save the enormous costs of projects
High Reliability
Hot standby of two servers will keep the system 7*24h stable operation
Long-term stability test make the hardware, OS and software more compatible

System
Items	DSS4004-S2
Client	PC Client	100
	DSS Mobile 2	100
	DSS Mobile for VDP	5000
Org. and User	Organization	10 hierarchies, 999 organizations per hierarchy
	User Group	3 Levels
	User	100 online users and unlimited users
Devices (Single Point Performance)	Video	512 Channels
	Onvif	64 IP, 64 Channels
	Access Control	100 IP, 512 Doors
	VDP Devices	1100 Devices (Unit VTO no more than 100)
	Facial Recognition Channels	32
	ANPR Camera	32
	Alarm Host	64
	POS Channels	32
	Time Attendance	64
Media Transmission Server	Video Input per Server	350 Mbps
	Video Output per Server	350 Mbps
Record	Playback Bandwidth per Server (With Recording)	150 Mbps
	Video Storage Bandwidth per Server	150 Mbps
	Maximum Capacity per Storage Server	200TB
	Download Task	UP to 5 per Client
Event	Number of event reception without Pic	80 per Second
	Number of event reception with Pic	5 per Second
Emap	Hierarchy of Raster Map	8 Hierarchies
	Photos of Raster Map	Up to 64 Photos
	Map size of Raster Map	Up to 14.7MB
	Channel Number	Up to 200
Personnel Management	Persons	30,000
	Cards	30,000
	Fingerprints	90,000
Other
Power	100V ~ 240V, 47 ~ 63Hz
Consumption	70W ~ 120W (with HDD)
Working Environment Temperature	0℃~ 45℃
Working Environment Humidity	5%~90% (non-condensation)
Storage Environment Temperature	-20℃~ ﹢70℃
Storage Environment Humidity	5% ~ 90% (non-condensation)
Working Altitude	-60m ~ 3000m
Weight (Without Package)	6.0Kg
Dimension	1U, 440mm×398.6mm×43.65 mm
Installation Method	Standard 19″ rack installation
