DSS7106D-S2

Categories: ,

A Powerful Surveillance System

Features:

  • High Performance
    • Supports 3.5”chassis with up to 15 hot plug hard drives and extend the storage via ISCSI
    • Supports up to 2000 video channels per server and it can extend the devices by distribution system
  • High Reliability
    • Backup the database automatically and manually, when something wrong happens, it can recover quickly
    • Hot standby application of two servers will keep the system 7*24h stable operation
Add to Enquiry List
System
Main Processor Intel i5-6600, 64 bits 4 Core Processor
Operating System Embedded Linux
Memory 8GB
Motherboard Embedded Board (support 7×24 operation)
Hard disk hot swap Hot swap and online replacement
Hard disk compatibility SAS/SATA disk intermixing to use
Interface
Number of Network Ports 4 Ethernet Ports (100/1000Mbps)
RS485 Reserved
RS232 Reserved
USB Front panel: 2× USB 2.0, Rear panel: 2 × USB 3.0
HDMI 3 HDMI
VGA 1 VGA
Storage
HDD Installation Support 15HDD disks (3.5″) for Video or Picture storage
(8TB per HDD)
Storage Up to 200TB per server
HDD Mode Single, Raid 0/1/5/6/10
Bandwidth of Video
Storage per Server		 700 Mbps
Other
Power Maximum power 315W, stable power 210W
Working Environment
Temperature		 0℃ ~ 40℃
Working Environment Humidity 10% ~ 80% (non-condensation)
Storage Environment Temperature -20℃ ~ ﹢70℃
Storage Environment Humidity 5% ~ 90% (non-condensation)
Working Altitude 0m ~ 5000m
Weight
(Without Package)		 19.1 Kg
Dimension 444.8mm×133.2mm×522.2mm
Installation method Standard 19-inch rack mount
Secondary development Provide the platform SDK
Performance Specification
Items DSS7016D-S2
Org. and User Organization 10 hierarchies, 999 organizations per hierarchy
Role (User Permission) 100
User 200 online users and 2500 users
User for VDP APP 500 online users and 5000 users
Devices
(Single Point Performance )		 Video 512 IP and 2000 channels
Auto-Register 500 IP and 2000 channels
ONVIF 200 IP and 200 channels
Access Control 200 IP，1024 Doors
VDP Devices 2000 VTH , 200 VTO
Attendance 200
Facial Recognition Channels 64
ANPR Camera 64
Object Detection 64
POS 64 (20 POS data per second)
Media Transmission Server Video Input per Server 700 Mbps
Video Output per Server 700 Mbps
Record Maximum Capacity per Storage Server 200TB
Download Task UP to 5 per Client
Emap Hierarchy of Raster Map 8 Hierarchies
Photos of Raster Map Up to 64 Photos
Map size of Raster Map Up to 14.7MB
Channel Number Up to 200
Personnel Management Persons 30,000
Cards 30,000
Fingerprints 90,000
Distribute
Devices Number of Connected Cameras 6000 IP and 10000 channels
Auto-Register 1000 IP and 4000 channels
ONVIF 1000 IP and 4000 channels
Number of Face recognition camera /
ANPR /
Object Detection /
POS /
Access Control 500 IP and 2500 doors
VDP 5000 VTH , 500 VTO
