EVS5016S

Categories: ,

16-HDD Enterprise Video Storage

Features:

  • Intel Processor
  • Max 320 IP Camera Inputs
  • Max 640Mbps Incoming/recording Bandwidth
  • 16 HDDs, SATA, Hot-Swap
  • Supports RAID 0/1/3/4/5/6/10/50/60/JBOD, Hotspare
  • iSCSI and Mini SAS for Expanded Storage Space
  • Support standard iSCSI Protocol Storage
  • Modular & Cableless Design
Add to Enquiry List
System
Main Processor 64-bit high-performance Intel processor
Controller Single controller
Memory 4GB by default
Working Mode
Video Stream Mode 320-channel (640Mbps) incoming and recording, 160-channel (320Mbps)forwarding, 32-channel (64Mbps) playback
Transfer Mode 4096 Mbps front-end connection
4096 Mbps network transfer
IP SAN Mode Storage bandwidth ≤2.7Gbps
Write-through: 320Mbps;Write-back: 480Mbps
Storage
HDD Amount 16 HDDs, Up to 10 TB capacity for each HDD
SATA HDD composite connection
miniSAS 1 miniSAS ports, for storage extension
HDD Installation Additional HDD bracket,
HDD hot-swap, HDD online replacement
HDD Mode Single, RAID0/1/3/4/5/6/10/50/60(Enterprise-level HDDs are recommended), JBOD, hotspare
Storage Management
HDD Manager Non-working HDD hibernation to guarantee sound ventilation, reduce power consumption and enhance HDD life span
HDD bad track mapping to enhance HDD life span
RAID Rebuild Dynamically adjust RAID rebuild speed to guarantee system load balance
Logic Volume Manager Support iSCSI volume management, NAS(SMB/NFS/FTP) volume management
Snapshot Support snapshot function, create user volume to back data.
Extract Frame Support extracting P frame function. Customizied extracting period and frame rate setup.
Cluster Service N+M cluster service
ANR After diconnection, system can download the record file from the SD card on the network camera to maintain the full record file
Shortcut RAID Creation Click one button to create RAID conveniently
Playback and Backup
Search Mode Time/Date, Channel, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Fast play, Slow play, Full screen, Backup selection, Digital zoom
Backup Mode USB Device/Network/eSATA Device
Third-party Support
Third-party Support AEBell, Arecont, AXIS, Dynacolor, HIKVISION, LG, Panasonic, PSIA, Samsung, Sony, Vivotec, and more
Recording
IP Camera Input 320 Channel
Record Rate 640 Mbps
Record Mode Manual, Schedule(Regular, Continous), Motion Detection, Alarm
Record Interval 1 ~ 120 min(default 60 min)
Pre-record 1 ~ 30 sec, Post-record 10 ~ 300 sec.
I frame storage by period.
Auxiliary Interface
USB 1 USB 3.0
Multiplex Interface 1 USB 2.0 & eSATA multiplex interface
RS232 1 Port, for PC communication and Keyboard
Network
Interface 2 data RJ-45 ports (10/100/1000Mbps)
Network Mode Multi-address, Fault-tolerance, Load balance, Link aggregation
Network Function HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTP, RTCP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, iSCSI, SMB, NFS, FTP, Alarm Server, IP Search (Support IP camera, DVR, NVS, etc.)
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4, CGI Conformant
Electrical
Power Supply AC100V ~ 240V, 47 ~ 63 Hz
Power Consumption < 200W (With HDD)
Environmental
Working Conditions 0°C ~ +40°C (+32°F ~ +104°F), 10 % ~ 80% RH
Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 5% ~ 90% RH
Working Altitude -60m ~ 3000m
Construction
Chassis 1.2mm extra-thickness hot-dip galvanized steel.
High accuracy aluminum alloy slider.
Self-developed patent removable HDD bracket.
Dimensions
(W x D x H)		 3U, 484.6mm x 473.6mm x 133.2mm ;
(19.1″ x 18.6″ x 5.2″)
Net Weight 10kg (22.0 lb) (without HDD)
Gross Weight 15kg (33.1 lb)
Installation Standard 19-inch rack installation
Certifications
CE EN55022, EN55024, EN50130-4, EN60950-1
FCC Part 15 Subpart B, ANSI C63.4-2009
