| Camera | |||||
| Image Sensor | 1/2.9" CMOS | ||||
| Effective Pixels | 1920(H)×1080(V), 2MP | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
||||
| Minimum Illumination | 0.02Lux/F2.0, 30IRE, 0Lux IR on | ||||
| S/N Ratio | More than 65dB | ||||
| IR Distance | Up to 50m (164feet) | ||||
| IR On/Off Control | Auto / Manual | ||||
| IR LEDs | 1 | ||||
| Lens | |||||
| Lens Type | Fixed lens / Fixed iris | ||||
| Mount Type | Board-in | ||||
| Focal Length | 3.6mm (2.8mm, 6mm Optional) | ||||
| Max Aperture | F2.0 | ||||
| Angle of View | H: 80.8° (106°/51°) | ||||
| Focus Control | – | ||||
| Close Focus Distance | 800mm (500mm/1900mm) 31.5” (19.7”74.8”) |
||||
| DORI Distance | ||||||
| Take RG59 as an example (Max. DC resistance < 5.0Ω/100m) | ||||||
| DORI Definition | Distance | |||||
| Detect | 25px/m (8px/ft) |
3.6mm: 57m(187ft) 2.8mm:45m(149ft) 6mm: 86m(281ft) |
||||
| Observe | 63px/m (19px/ft) |
3.6mm: 23m(75ft) 2.8mm:18m(59ft) 6mm:34m(113ft) |
||||
| Recognize | 125px/m (38px/ft) |
3.6mm: 11m(37ft) 2.8mm:9m(30ft) 6mm: 17m(56ft) |
||||
| Identify | 250ppm (76px/ft) |
3.6mm: 6m(19ft) 2.8mm:5m(15ft) 6mm: 9m(28ft) |
||||
| Pan/ Tilt/ Rotation | ||||||
| Pan/ Tilt/ Rotation | Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360° |
|||||
| Video | ||||||
| Resolution | 1080P (1920×1080) | |||||
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |||||
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) | |||||
| Day/Night | Auto (ICR) / Manual | |||||
| OSD Menu | Multi-language | |||||
| BLC Mode | BLC / HLC / DWDR | |||||
| WDR | DWDR | |||||
| Gain Control | AGC | |||||
| Noise Reduction | 2D | |||||
| White Balance | Auto / Manual | |||||
| Smart IR | Auto / Manual | |||||
| Certifications | ||||||
| Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|||||
| Interface | ||||||
| Audio Interface | Built-in Mic | |||||
| Electrical | ||||||
| Power Supply | 12V DC ±25% | |||||
| Power Consumption | Max 2.9W (12V DC, IR on) | |||||
| Environmental | ||||||
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH *Start up should be done at above -40°C (-40°F) |
|||||
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH | |||||
| Ingress Protection & Vandal Resistance | IP67 | |||||
| Construction | ||||||
| Casing | Aluminium | |||||
| Dimensions | Φ106mm×93.7mm (Φ4.17"×3.69") | |||||
| Net Weight | 0.44kg (0.97lb) | |||||
| Gross Weight | 0.58kg (1.28lb) | |||||
