| Camera | |||||
| Image Sensor | 1/3″ CMOS | ||||
| Effective Pixels | 1280(H)×720(V), 1MP | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
||||
| Minimum Illumination | 0.05Lux/F1.3, 30IRE, 0Lux IR on | ||||
| S/N Ratio | More than 65dB | ||||
| IR Distance | Up to 60m (197feet) | ||||
| IR On/Off Control | Auto / Manual | ||||
| IR LEDs | 4 | ||||
| Lens | |||||
| Lens Type | Vari-focal lens / Fixed iris | ||||
| Mount Type | Board-in | ||||
| Focal Length | 2.7-13.5mm | ||||
| Max Aperture | F1.3 | ||||
| Angle of View | H: 91°~25° | ||||
| Focus Control | Manual | ||||
| Close Focus Distance | 200mm 7.87” |
||||
| DORI Distance | ||||
| Take RG59 as an example (Max. DC resistance < 5.0Ω/100m) | ||||
| DORI Definition | Distance | |||
| Wide | Tele | |||
| Detect | 25px/m (8px/ft) |
34m(112ft) | 118m(388ft) | |
| Observe | 63px/m (19px/ft) |
14m(45ft) | 47m(155ft) | |
| Recognize | 125px/m (38px/ft) |
7m(22ft) | 24m(78ft) | |
| Identify | 250ppm (76px/ft) |
3m(11ft) | 12m(39ft) | |
| Pan/ Tilt/ Rotation | ||||||
| Pan/ Tilt/ Rotation | Pan: 0° ~360° Tilt: 0° ~ 87° Rotation: 0° ~ 360° |
|||||
| Video | ||||||
| Resolution | 720P (1280×720) | |||||
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |||||
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) | |||||
| Day/Night | Auto (ICR) / Manual | |||||
| OSD Menu | Multi-language | |||||
| BLC Mode | BLC / HLC / DWDR | |||||
| WDR | DWDR | |||||
| Gain Control | AGC | |||||
| Noise Reduction | 2D | |||||
| White Balance | Auto / Manual | |||||
| Smart IR | Auto / Manual | |||||
| Certifications | ||||||
| Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|||||
| Interface | ||||||
| Audio Interface | – | |||||
| Electrical | ||||||
| Power Supply | 12V DC ±25% | |||||
| Power Consumption | Max 7.0W (12V DC, IR on) | |||||
| Environmental | ||||||
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH *Start up should be done at above -40°C (-40°F) |
|||||
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140F) / Less than 90% RH | |||||
| Ingress Protection & Vandal Resistance | IP67 | |||||
| Construction | ||||||
| Casing | Aluminium | |||||
| Dimensions | 213.0mm×90.4mm×90.4mm (8.39″×3.56″×3.56″) | |||||
| Net Weight | 0.55kg (1.21lb) | |||||
| Gross Weight | 0.68kg (1.50lb) | |||||
