| Camera | |||||
| Image Sensor | 1/3” 3Megapixel progresive CMOS | ||||
| Effective Pixels | 2304H)x1536(V) | ||||
| RAM/ROM | 256MB/16MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | ||||
| Minimum Illumination | 0.1Lux/F2.0(Color), 0Lux/F2.0(IR on) | ||||
| S/N Ratio | More than 50dB | ||||
| IR Distance | Distance up to 30m(98ft) | ||||
| IR On/Off Control | Auto / Manual | ||||
| IR LEDs | 24 | ||||
| Lens | |||||
| Lens Type | Fixed | ||||
| Mount Type | Board-in | ||||
| Focal Length | 2.8 mm (3.6 mm optional) | ||||
| Max Aperture | F2.0/F2.0 | ||||
| Angle of View | H:98°/77°, V:51°/41° | ||||
| Focus Control | Fixed | ||||
| Close Focus Distance | – | ||||
| DORI Distance | ||||
| DORI Distance | ||||
| 2.8 mm Lens | 3.6 mm Lens | |||
| Detect | 58m(190ft) | 73m(240ft) | ||
| Observe | 23m(75ft) | 29m(95ft) | ||
| Recognize | 12m(39ft) | 15m(49ft) | ||
| Identify | 6m(20ft) | 7m(23ft) | ||
| PTZ | ||||||
| Pan/ Tilt Range | Pan: 0° ~355° Tilt: 0° ~65° Rotation: 0° ~ 355° |
|||||
| Video | ||||||
| Compression | H.264+/H.264 | |||||
| Streaming Capability | 2 Streams | |||||
| Resolution | 3M(2048×1536)(2304×1296)/1080P(1920×1080)/1.3M(1280×960)720P(1280×720)/ D1(704×576/704×480)/CIF(352×288/352×240) | |||||
| Frame Rate | 3M(1 ~ 20fps)/2M (1 ~ 25/30fps)s) D1/CIF(1 ~ 25/30fps) |
|||||
| Bit Rate Control | 1-channel BNC high definition video output / CVBS video output (Can switch) | |||||
| Bit Rate | H264:24K ~ 8192Kbps | |||||
| Day/Night | Auto(ICR) / Color / B/W | |||||
| BLC Mode | BLC / HLC / DWDR | |||||
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | |||||
| Gain Control | Auto/Manual | |||||
| Noise Reduction | 3D DNR | |||||
| Motion Detection | Off / On (4 Zone, Rectangle) | |||||
| Region of Interest | Off / On (4 Zone) | |||||
| Electronic Image | Support | |||||
| Smart IR | Support | |||||
| Digital Zoom | 16x | |||||
| Flip | 0°/90°/180°/270° | |||||
| Mirror | Off / On | |||||
| Privacy Masking | Off / On (4 Area, Rectangle) | |||||
| Certifications | ||||||
| Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|||||
| Audio | ||||||
| Compression | – | |||||
| Network | ||||||
| Ethernet | RJ-45 (10/100Base-T) | |||||
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP; |
|||||
| Interoperability | ONVIF, PSIA, CGI | |||||
| Streaming Method | Unicast / Multicast | |||||
| Max. User Access | 10 Users/20 Users | |||||
| Edge Storage | NAS(Network Attached Storage),Local PC for instant recording | |||||
| Web Viewer | IE, Chrome, Firefox, Safari | |||||
| Management Software | Smart PSS, DSS,Easy4ip | |||||
| Smart Phone | iPhone, iPad, Android Phone | |||||
| Interface | ||||||
| Video Interface | – | |||||
| Audio Interface | – | |||||
| RS485 | – | |||||
| Alarm | – | |||||
| Electrical | ||||||
| Power Supply | DC12V PoE (802.3af)(Class 0) | |||||
| Power Consumption | <5.0W | |||||
| Environmental | ||||||
| Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Storage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Ingress Protection & Vandal Resistance | IP67,IK10 | |||||
| Construction | ||||||
| Casing | Metal | |||||
| Dimensions | Φ109.9mm × 81mm (4.33″ x 3.19″) | |||||
| Net Weight | 0.34Kg (0.75lb) | |||||
| Gross Weight | 0.47Kg (1.04lb) | |||||
