| Camera | |||||
| Image Sensor | 1/2.8” 2Megapixel progressive CMOS | ||||
| Effective Pixels | 1920(H) x1080(V) | ||||
| RAM/ROM | 256MB/32MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | ||||
| Minimum Illumination | 0.006Lux/F1.4( Color,1/3s,30IRE) 0.05Lux/F1.4( Color,1/30s,30IRE) 0Lux/F1.4(IR on) |
||||
| S/N Ratio | More than 50dB | ||||
| IR Distance | Distance up to 30m(98ft) | ||||
| IR On/Off Control | Auto/ Manual | ||||
| IR LEDs | 2 | ||||
| Lens | |||||
| Lens Type | Motorized(-ZS),Manual(-VFS) | ||||
| Mount Type | Board-in | ||||
| Focal Length | 2.7mm~13.5mm | ||||
| Max Aperture | F1.4 | ||||
| Angle of View | H:106°~29°, V:57°~17° | ||||
| Focus Control | Motorized(-ZS),Manual(-VFS) | ||||
| Close Focus Distance | 0.2m | ||||
| DORI Distance | ||||
| DORI Distance | ||||
| W | T | |||
| Detect | 46m(151ft) | 153m(502ft) | ||
| Observe | 18m(59ft) | 61m(200ft) | ||
| Recognize | 9m(30ft) | 30m(98ft) | ||
| Identify | 5m(16ft) | 15m(49ft) | ||
| PTZ | ||||||
| Pan/ Tilt/ Range | Pan: 0° ~355° Tilt: 0° ~75° Rotation: 0° ~ 355° |
|||||
| Intelligence | ||||||
| Event Trigger | Motion detection, Video tampering,Scene changing,Network disconnection,IP address conflict,Illegal acess,Storage anomaly | |||||
| IVS | Tripwire, Intrusion | |||||
| Video | ||||||
| Compression | H.265/H.264H/MJPEG(Sub Stream) | |||||
| Smart Codec | Support H.265+/H.264+ | |||||
| Streaming Capability | 2 Streams | |||||
| Resolution | 1080P(1920×1080)/1.3M(1280×960)/ 720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240) |
|||||
| Frame Rate | Main Stream: 1080P(1 ~ 25/30fps) Sub Stream: D1(1 ~ 25/30fps) |
|||||
| Bit Rate Control | CBR/VBR | |||||
| Bit Rate | H.265: 12K ~ 6400Kbps H.264: 32K ~ 10240Kbps |
|||||
| Day/Night | Auto(ICR) / Color / B/W | |||||
| BLC Mode | BLC / HLC / WDR(120dB) | |||||
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | |||||
| Gain Control | Auto/Manual | |||||
| Noise Reduction | 3D DNR | |||||
| Motion Detection | Off / On (4 Zone, Rectangle) | |||||
| Region of Interest | Off / On (4 Zone) | |||||
| Electronic Image | Support | |||||
| Smart IR | Support | |||||
| Digital Zoom | 16x | |||||
| Flip | 0°/90°/180°/270° | |||||
| Mirror | Off / On | |||||
| Privacy Masking | Off / On (4 Area, Rectangle) | |||||
| Certifications | ||||||
| Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|||||
| Audio | ||||||
| Compression | – | |||||
| Network | ||||||
| Ethernet | RJ-45 (10/100Base-T) | |||||
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP; FTP;DHCP;DNS;DDNS;PPPoE;IPv4/v6;QoS;UPnP; NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP; TLS |
|||||
| Interoperability | ONVIF Profile S&G, API | |||||
| Streaming Method | Unicast / Multicast | |||||
| Max. User Access | 10 Users/20 Users | |||||
| Edge Storage | NAS Local PC for instant recording Micro SD Card 128GB |
|||||
| Web Viewer | IE, Chrome, Firefox, Safari | |||||
| Management Software | Smart PSS, DSS, DMSS | |||||
| Smart Phone | IOS, Android | |||||
| Interface | ||||||
| Video Interface | – | |||||
| Audio Interface | – | |||||
| RS485 | – | |||||
| Alarm | – | |||||
| Electrical | ||||||
| Power Supply | DC12V, PoE (IEEE802.3af)(Class 0) | |||||
| Power Consumption | <9W(-ZS), <7W(-VFS) | |||||
| Environmental | ||||||
| Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Storage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Ingress Protection | IP67 | |||||
| Vandal Resistance | IK10 | |||||
| Construction | ||||||
| Casing | Metal | |||||
| Dimensions | φ122mm×88.9mm(4.80”x3.50”) | |||||
| Net Weight | 0.4Kg (0.88lb) | |||||
| Gross Weight | 0.54Kg(1.19lb) | |||||
