| Camera | |||||
| Image Sensor | 1/2.8” 2Megapixel progressive scan CMOS | ||||
| Effective Pixels | 1920(H)x1080(V) | ||||
| RAM/ROM | 256MB/32MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | ||||
| Minimum Illumination | 0.009Lux/F2.0( Color,1/3s,30IRE) 0.07Lux/2.0( Color,1/30s,30IRE) 0Lux/F2.0(IR on) |
||||
| S/N Ratio | More than 50dB | ||||
| IR Distance | Distance up to 40m (131ft) | ||||
| IR On/Off Control | Auto/ Manual | ||||
| IR LEDs | 2 | ||||
| Lens | |||||
| Lens Type | Fixed | ||||
| Mount Type | Board-in | ||||
| Focal Length | 3.6mm (6mm optional) | ||||
| Max Aperture | F2.0 (F2.0) | ||||
| Angle of View | H: 87° (51°), V: 48° (30°) | ||||
| Optical Zoom | – | ||||
| Focus Control | Fixed | ||||
| Close Focus Distance | – | ||||
| DORI Distance | ||||
| DORI Distance | ||||
| 3.6 mm | 6.0 mm | |||
| Detect | 55m(180ft) | 81m(266ft) | ||
| Observe | 22m(72ft) | 32m(105ft) | ||
| Recognize | 11m(36ft) | 16m(52ft) | ||
| Identify | 6m(20ft) | 8m(26ft) | ||
| PTZ | ||||||
| Pan/ Tilt Range | Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ | |||||
| Intelligence | ||||||
| IVS | Tripwire, Intrusion, Object Abandoned/Missing | |||||
| Advanced Intelligent Functions | Face Detection | |||||
| Video | ||||||
| Compression | H.265+/H.265/H.264+/H.264 | |||||
| Smart Codec | Support H.265+/H.264+ | |||||
| Streaming Capability | 3 Streams | |||||
| Resolution | 1080P(1920×1080)/1.3M(1280×960)/ 720P(1280×720)/D1(704×576/704×480)/ VGA(640×480)/CIF(352×288/352×240) | |||||
| Frame Rate | Main Stream: 1080P(1~50/60fps) Sub Stream: D1(1~50/60fps) Third Stream: 1080P(1~25/30fps) |
|||||
| Bit Rate Control | CBR/VBR | |||||
| Bit Rate | H.264: 24~9472Kbps H.265: 14~5632Kbps |
|||||
| Day/Night | Auto(ICR) / Color / B/W | |||||
| BLC Mode | BLC / HLC / WDR(120dB) | |||||
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | |||||
| Gain Control | Auto/Manual | |||||
| Noise Reduction | 3D DNR | |||||
| Motion Detection | Off / On (4 Zone, Rectangle) | |||||
| Region of Interest | Off / On (4 Zone) | |||||
| Electronic Image | – | |||||
| Smart IR | Support | |||||
| Defog | – | |||||
| Digital Zoom | 16x | |||||
| Flip | 0°/90°/180°/270° | |||||
| Mirror | Off / On | |||||
| Privacy Masking | Off / On (4 Area, Rectangle) | |||||
| Certifications | ||||||
| Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|||||
| Audio | ||||||
| Compression | – | |||||
| Network | ||||||
| Ethernet | RJ-45 (10/100Base-T) | |||||
| Protocol | HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;IGMP; SNMP |
|||||
| Interoperability | ONVIF, PSIA, CGI | |||||
| Streaming Method | Unicast / Multicast | |||||
| Max. User Access | 10 Users/20 Users | |||||
| Edge Storage | NAS Local PC for instant recording Micro SD Card 128GB |
|||||
| Web Viewer | IE, Chrome, Firefox, Safari | |||||
| Management Software | Smart PSS, DSS, Easy4ip | |||||
| Smart Phone | IOS, Android | |||||
| Interface | ||||||
| Video Interface | – | |||||
| Audio Interface | – | |||||
| RS485 | – | |||||
| Alarm | – | |||||
| Electrical | ||||||
| Power Supply | DC12V, PoE (802.3af)(Class 0) | |||||
| Power Consumption | <6W | |||||
| Environmental | ||||||
| Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Strorage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Ingress Protection | IP67 | |||||
| Vandal Resistance | – | |||||
| Construction | ||||||
| Casing | Metal | |||||
| Dimensions | 180mm×70mm×70mm (7.09”×2.76”×2.76”) | |||||
| Net Weight | 0.41kg (0.91lb) | |||||
| Gross Weight | 0.53 kg (1.17lb) | |||||
