| Camera | |||||
| Image Sensor | 1/2.8” 2Megapixel progressive scan CMOS | ||||
| Effective Pixels | 1920(H)x1080(V) | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | ||||
| Minimum Illumination | 0.02Lux/F2.4 (Color,1/3s,30IRE) 0.08Lux/F2.4 (Color,1/30s,30IRE) 0.01Lux/F2.4 (B/W,1/3s,30IRE) 0.04Lux/F2.4 (B/W,1/30s,30IRE) |
||||
| IR Distance | – | ||||
| IR On/Off Control | – | ||||
| IR LEDs | – | ||||
| Lens | |||||
| Lens Type | Fixed | ||||
| Mount Type | Board-in | ||||
| Focal Length | 2.8mm | ||||
| Max Aperture | F2.4 | ||||
| Angle of View | H:104° ,V:59° | ||||
| Optical Zoom | – | ||||
| Focus Control | Fixed | ||||
| Close Focus Distance | – | ||||
| DORI Distance | ||||
| DORI Distance | ||||
| Detect | 38m(126ft) | |||
| Observe | 15m(50ft) | |||
| Recognize | 8m(25ft) | |||
| Identify | 4m(12ft) | |||
| Pan/Tilt/Rotation | ||||||
| Pan/ Tilt/Rotation Range | – | |||||
| Certifications | ||||||
| Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|||||
| Environmental | ||||||
| Operating Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Strorage Conditions | -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH | |||||
| Ingress Protection | – | |||||
| Vandal Resistance | – | |||||
| Construction | ||||||
| Casing | Metal | |||||
| Dimensions | Φ30.5mm×48.65mm(Φ1.20”×1.91”) | |||||
| Net Weight | 0.40Kg (0.88lb) | |||||
| Gross Weight | 0.47Kg (1.03lb) | |||||
