| Hardware | |||||
| Ethernet Port | Port 1-8: 8 × 10/100/1000 Base-T (PoE) Port 9-10: 2 × 10/100/1000 Base-T Port 11-12: 2 × 1000 Base-X |
||||
| PoE Power Consumption | Port 1-2 ≤ 60W (Hi-PoE) Port 3-8 ≤ 30W, total ≤ 96W | ||||
| PoE Protocol | IEEE802.3af, IEEE802.3at, Hi-PoE | ||||
| Power Supply Pin | PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-); Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) | ||||
| Switching Capacity | 52 Gbps | ||||
| Packet Forwarding Rate | 17.856 Mpps | ||||
| Packet Buffer Memory | 4 Mbits | ||||
| MAC Address Table | 8K | ||||
| Operating Humidity | 5%RH–95%RH | ||||
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) | ||||
| Power Input | 48V DC-57V DC | ||||
| Lightning Protection | Common mode: 2KV Differential mode: 1KV Class B Electromagnetic Compatibility Standard |
||||
| Power Consumption | Idle: 12W PoE full load: 96W |
||||
| Weight | 0.84 kg (1.85 lb) Box weight (with accessory): 1.75 kg (3.86 lb) Box in protective box: 8 in 1. Protective box weight (with accessory): 14.5 kg (31.97 lb) |
||||
| Dimension (W×D×H) | 220 mm × 135 mm × 30 mm (8.67″ × 5.31″ × 1.18″) Box dimension: 290 mm × 196 mm × 91 mm (11.42” × 7.72” × 3.58″) Protective box dimension: 597 mm × 392 mm × 230 mm (23.50″ × 15.43″ × 9.06″) |
||||
| Software | |||||
| System | Username/password: admin/admin | ||||
| IP address: 192.168.1.110/24 | |||||
| NTP | Yes | ||||
| DHCP | DHCP-Client, DHCP-Server | ||||
| VLAN | 802.1Q Standard VLAN | ||||
| Port Aggregation | Static link aggregation | ||||
| Dynamic link aggregation | |||||
| Mirroring | Many-to-one port mirroring | ||||
| Flow Control | Half-duplex based on back pressure type control | ||||
| Full duplex based on PAUSE frame | |||||
| IGMP Snooping | IGMP snooping based on port | ||||
