| Camera | |||||
| Image Sensor | 1/2.7” CMOS | ||||
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels | ||||
| RAM/ROM | 256M/128M | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | 1/1s~1/30,000s | ||||
| Minimum Illumination | Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6; 0Lux@F1.6 (IR on) | ||||
| S/N Ratio | More than 50dB | ||||
| IR Distance | Distance up to 30m (98ft) | ||||
| IR On/Off Control | Auto/Manual | ||||
| IR LEDs | 4 | ||||
| Lens | |||||
| Focal Length | 2.7mm~11mm | ||||
| Max Aperture | F1.6 | ||||
| Angle of View | H: 112.5° ~ 30° | ||||
| Optical Zoom | 4x | ||||
| Focus Control | Auto/Manual | ||||
| Close Focus Distance | 100mm~ 1000mm | ||||
| DORI Distance | ||||
| Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. | ||||
| Detect | 120m(394ft) | |||
| Observe | 48m(157ft) | |||
| Recognize | 24m(79ft) | |||
| Identify | 12m(39ft) | |||
| PTZ | ||||||
| Pan/ Tilt Range | Pan: 0° ~ 360° limited; Tilt: 0° ~ 90° | |||||
| Manual Control Speed | Pan: 0.1° ~100° /s; Tilt: 0.1° ~60° /s | |||||
| Preset Speed | Pan: 100° /s; Tilt: 60° /s | |||||
| Presets | 300 | |||||
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan ,Auto Scan | |||||
| Speed Setup | Human-oriented focal Length/ speed adaptation | |||||
| Power up Action | Auto restore to previous PTZ and lens status after power failure | |||||
| Idle Motion | Activate Preset/Tour if there is no command in the specified period | |||||
| Protocol | DH-SD | |||||
| Intelligence | ||||||
| Event Trigger | Motion detection, Video tampering, Network disconnection, IP address conflict, Illegal access, Storage anomaly | |||||
| Auto Tracking | – | |||||
| IVS | Tripwire, Intrusion, Object Abandoned/Missing | |||||
| Advanced Intelligent Functions | Face Detection | |||||
| Video | ||||||
| Compression | H.264+/H.264/MJPEG | |||||
| Streaming Capability | 3 Streams | |||||
| Resolution | 1080P(1920×1080)/720P(1280×720) /D1(704×576/704×480)/CIF(352×288/352×240) |
|||||
| Frame Rate | Main stream: 1080P/720P/D1 (1 ~ 25/30fps) Sub stream1: D1/CIF(1 ~ 25/30fps) Sub stream2: 720P/D1/CIF (1 ~ 25/30fps) |
|||||
| Bit Rate Control | CBR/VBR | |||||
| Bit Rate | H.264+/H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps | |||||
| Day/Night | Auto(ICR) / Color / B/W | |||||
| BLC Mode | BLC / HLC / WDR(120dB) | |||||
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | |||||
| Gain Control | Auto/Manual | |||||
| Noise Reduction | Ultra DNR (2D/3D) | |||||
| Motion Detection | Support | |||||
| Region of Interest | Support | |||||
| Electronic Image | – | |||||
| Smart IR | Support | |||||
| Digital Zoom | 16x | |||||
| Flip | 180° | |||||
| Privacy Masking | Up to 24 areas | |||||
| Certifications | ||||||
| Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|||||
| Audio | ||||||
| Compression | G.711a/G.711u(32kbps)/PCM(128kbps) | |||||
| Network | ||||||
| Ethernet | RJ-45 (10XBase-T/100Base-TX) | |||||
| Wi-Fi | – | |||||
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x | |||||
| Interoperability | ONVIF Profile S&G, API | |||||
| Streaming Method | Unicast / Multicast | |||||
| Max. User Access | 20 users | |||||
| Edge Storage | NAS Local PC for instant recording Micro SD Card 128GB |
|||||
| Web Viewer | IE, Chrome, Firefox, Safari | |||||
| Management Software | Smart PSS, DSS, DMSS | |||||
| Smart Phone | IOS, Android | |||||
| Interface | ||||||
| Video Interface | – | |||||
| RS485 | – | |||||
| Audio I/O | Built-in Mic | |||||
| Alarm I/O | – | |||||
| Electrical | ||||||
| Power Supply | DC 12V/1.5A, PoE(802.3af) | |||||
| Power Consumption | 10W,13W (IR on) | |||||
| Environmental | ||||||
| Operating Conditions | -30°C ~ 60°C (-22°F ~ +140°F) / Less than 90% RH | |||||
| Ingress Protection | – | |||||
| Vandal Resistance | – | |||||
| Construction | ||||||
| Casing | Metal | |||||
| Dimensions | Φ132.7 (mm) x 117.9 (mm) | |||||
| Net Weight | 0.95kg(2.09lb) | |||||
| Gross Weight | 1kg(2.20lb) | |||||
