| Camera | |||||
| Image Sensor | 1/2.8” STARVIS™ CMOS | ||||
| Effective Pixels | 1920(H) x 1080(V), 2 Megapixels | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | 1/1s~1/30,000s | ||||
| Minimum Illumination | Color: 0.005Lux@F1.6; B/W:0.0005Lux@F1.6 | ||||
| S/N Ratio | More than 50dB | ||||
| IR Distance | – | ||||
| IR On/Off Control | – | ||||
| IR LEDs | – | ||||
| Lens | |||||
| Focal Length | 5.3mm~64mm | ||||
| Max Aperture | F1.6 ~ F3.0 | ||||
| Angle of View | H: 58.4° ~ 4.9° | ||||
| Optical Zoom | 12x | ||||
| Focus Control | Auto/Manual | ||||
| Close Focus Distance | 100mm~ 1000mm | ||||
| DORI Distance | ||||
| Take RG59 as an example (Max. DC resistance < 5.0Ω/100m) | ||||
| Distance | ||||
| Detect | Observe | Recognize | Identify | |
| 883m(2897ft) | 353m(1158ft) | 177m(581ft) | 88m(289ft) | |
| PTZ | ||||||
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°,auto flip 180° | |||||
| Manual Control Speed | 4MP (2560×1440) | |||||
| Preset Speed | 25/30fps@4MP, 25/30fps@1080P, 25/30fps@720P | |||||
| Presets | 1-channel BNC high definition video output / CVBS video output (Can switch) | |||||
| PTZ Mode | Auto (ICR) / Manual | |||||
| Speed Setup | Multi-language | |||||
| Power up Action | BLC / HLC / DWDR | |||||
| Idle Motion | DWDR | |||||
| Protocol | AGC | |||||
| Video | ||||||
| Resolution | 1080P(1920×1080)/720P(1280×720) | |||||
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |||||
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) | |||||
| Day/Night | Auto(ICR) / Color / B/W | |||||
| OSD Menu | Support | |||||
| Backlight Compensation | BLC / HLC / WDR(120dB) | |||||
| White Balance | Auto, ATW, Indoor, Outdoor, Manual | |||||
| Gain Control | Auto / Manual | |||||
| Noise Reduction | Ultra DNR (2D/3D) | |||||
| Digital Zoom | 16x | |||||
| Flip | 180° | |||||
| Privacy Masking | Up to 24 areas | |||||
| Certifications | ||||||
| Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
|||||
| Interface | ||||||
| Video Interface | 1 | |||||
| Audio Interface | 1 channel in | |||||
| RS485 | 1 | |||||
| Alarm I/O | 2/1 | |||||
| Electrical | ||||||
| Power Supply | 12V DC ±25% | |||||
| Power Consumption | Max 4.1W (12V DC, IR on) | |||||
| Environmental | ||||||
| Operating Conditions | -30°C ~ 60°C (-22°F ~ +140°F) / Less than 90% RH | |||||
| Ingress Protection | – | |||||
| Vandal Resistance | IK10 | |||||
| Construction | ||||||
| Casing | Metal | |||||
| Dimensions | Φ198(mm) x 158(mm) | |||||
| Net Weight | 2.3kg(5.07lb) | |||||
| Gross Weight | 3.3kg(7.28lb) | |||||
